WhatsApp Disconnected Trigger

The WhatsApp Disconnected trigger is a custom Whatsapp provider workflow trigger that fires automatically whenever a WhatsApp number disconnects from your CRM. Use it to build automated alerts, create reconnection tasks, or notify your team instantly when a connection is lost.

Key Benefits​

Instant Alerts - Know immediately when a WhatsApp number goes offline

Prevent Missed Messages - Take action before leads go unanswered

Multi-Account Monitoring - Track disconnections across all your sub-accounts

Automated Recovery - Trigger notifications to reconnect quickly

Zero Manual Monitoring - No need to constantly check connection status

Who Should Use It​

Agencies - Monitor client WhatsApp numbers and alert account managers instantly

Teams with multiple numbers - Track which numbers need attention across locations

High-volume operations - Ensure 24/7 WhatsApp availability for lead response

Remote teams - Get notified when field devices lose connection

Requirements​

Before using this trigger, update your Whatsapp provider app to the latest version:

  1. Go to App Marketplace → Installed Apps
  2. Find Whatsapp provider
  3. Click Update if available

How to Set Up​

Step 1: Create a New Workflow​

  1. Go to Automation → Workflows
  2. Click Create Workflow or + Add
  3. Select Start from Scratch

Step 2: Add the Trigger​

  1. Click Add New Trigger
  2. Switch to the Apps tab (not the default triggers)
  3. Find and click the Whatsapp provider app icon
  4. Select WhatsApp Disconnected from the dropdown
  5. Click Save trigger

WhatsApp Disconnect Triggers

Step 3: Add Your Actions​

Add any actions you want to execute when disconnection occurs:

  • Send Email → Alert admin team
  • Send SMS → Notify account owner
  • Create Task → Assign reconnection task
  • Send Slack Message → Alert your team channel
  • Internal Notification → Notify CRM users

Step 4: Save and Publish​

  1. Review your workflow
  2. Click Save
  3. Toggle workflow from Draft to Published

Available Trigger Variables​

When the trigger fires, these variables become available for use in your workflow actions. Insert them by clicking the tag icon in any field or typing with double curly braces.

VariableDescriptionExample Value
{{whatsapp_disconnected_prod.payload.instance.phoneNumber}}The disconnected phone number+1234567890
{{whatsapp_disconnected_prod.payload.instance.instanceIndex}}Instance identifier index1
{{whatsapp_disconnected_prod.payload.channelType}}The channel typewhatsapp
{{whatsapp_disconnected_prod.locationId}}The CRM location IDabc123xyz

Example Use Cases​

Use Case 1: Email Alert to Admin​

Send an immediate email when any WhatsApp number disconnects.

Trigger: WhatsApp Disconnected

Action: Send Email

Alert: WhatsApp Number Disconnected

Phone Number: {{whatsapp_disconnected_prod.payload.instance.phoneNumber}}
Location ID: {{whatsapp_disconnected_prod.locationId}}

This number is now offline. Please reconnect immediately.

Use Case 2: Create Reconnection Task​

Automatically create a high-priority task for your operations team.

Trigger: WhatsApp Disconnected

Action: Create Task

  • Title: 🔴 Reconnect WhatsApp: {{whatsapp_disconnected_prod.payload.instance.phoneNumber}}
  • Description: This WhatsApp number has disconnected. Please reconnect immediately.
  • Assign to: Operations Manager
  • Priority: High

Important Notes​

Technical Details​

  • The trigger fires once per disconnection event
  • Works for both manual disconnections and unexpected disconnections
  • Executes immediately when disconnection is detected
  • Works across all WhatsApp instances in the location

Best Practices​

  • Set up multiple notification channels for critical numbers
  • Include the phone number variable in all notifications for quick identification
  • Create high-priority tasks with immediate due dates
  • Test your workflow by manually disconnecting a test number

FAQs​

Will the trigger fire if I manually disconnect WhatsApp?​

Yes. The trigger fires for all disconnection events—whether manual, network-related, or unexpected.

Can I use this trigger with multiple actions?​

Yes. You can add as many actions as needed to a single workflow. They will execute in sequence when the trigger fires.

Why can't I send a WhatsApp message when this trigger fires?​

When the trigger fires, your WhatsApp number is already offline and cannot send messages. Use alternative notification methods like email, SMS, or Slack.

How quickly does the trigger fire after disconnection?​

The trigger fires immediately when the disconnection is detected—typically within seconds of the actual event.
